300W 20A DC-DC Buck Converter Step Down Module
korte omschrijving
6-40volt naar 1.2-36v DC-DC buck convertor 20 Ampere.
Homepage
Niet beschikbaar
Beschikbaarheid
6 op voorraad en direct leverbaar
Aanbevelen

Voorraad:6

Komt voor in
  • Algemeen
  • Hobby home
  • Elektronica home

300W 20A DC-DC Buck Converter Step Down Module

Features:

  • With a wide input voltage range from 6V to 40V, the step-down converter can accurately adjust output voltage and current.
  • The efficiency can be up to 96%, measured at 20A, converting 24V to 12V.
  • It is designed with 75V/80A large current dual MOS tube.
  • Input and output use high frequency low resistance electrolytic capacitor, low ripple, stable output.
  • Wiring is convenient with these large current 30A screw terminals.
  • The buck module has 2 heat sink that could enhance heat dissipation.
  • When there is a big difference between input and output voltage, please decrease power and current.

Specifications:

  • Input Voltage: 6V to 40V DC(10V to 40V is suggested)
  • Output Voltage: 1.2V to 36V DC
  • Output Current: 20A(max.), 15A(suggested)
  • Efficiency: 95%(24V to 12V, 20A)
  • Output Ripple: ≤50mV
  • Wiring Method: Terminal
  • Short Circuit Protection: Self-recovery(cannot short circuit for long time)
  • Size: 60 x 53 x 27mm
