Product
LJ12A3-4-Z/BY 4mm Inductive Proximity Sensor
korte omschrijving
 Inductieve afstand sensor. Detectie afstand +/- 4mm
Homepage
Niet beschikbaar
Beschikbaarheid
Niet op voorraad, levertijd onbekend. Als je wil weten of, of wanneer het product leverbaar is, neem dan contact op met de shop.
Aanbevelen

Niet op voorraad

Komt voor in
  • Algemeen
  • Hobby home
  • Elektronica home
  • CNC home

LJ12A3-4-Z/BY 4mm Inductive Proximity Sensor

Model LJ12A3-4-Z/BX Tubular Inductive Proximity Sensor Switch NPN 3 Wire DC 6-36V

Specification

  • Model: LJ12A3-4-Z / BY
  • Operating Voltage: DC 6-36V range within Universal
  • Output Type: PNP normally open three-line
  • Detection object: metal objects
  • Detection distance: 4 mm
  • Output Current: 300 mA
  • Response Frequency : 0.5KH
  • Working temperature: Temperature range -30 ° - = 60 °, + 23 ° within+ (-) 15% detection distance
  • Temperature range -25 ° + 60 °, + 23 °, within + (-) 10% detection distance
  • Dimensions: 12 mm screw diameter, 55mm length
  • Cable length: about 190 cm
  • Material: metal and plastic

Serie

  • LJ12A3-4-Z/BY: PNP NO 3-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/AY: PNP NC 3-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/BX: NPN NO 3-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/AX: NPN NC 3-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/CX: NPN NO+NC 4-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/CY: PNP NO+NC 4-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/EX: NO 2-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-Z/DX: NC 2-Line DC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-J/EZ: NO 2-Line AC type 12mm diameter ; 4mm detection distance
  • LJ12A3-4-J/DZ: NC 2-Line AC type 12mm diameter ; 4mm detection distance
