DSO150 15001K Digital Oscilloscope (gebruiks klaar)

kant en klare mini osciloscoop. inclusief 1x, 10x probe.

Specifications:

• Number of channel: 1
• Analog bandwidth: 0 - 200KHz
• Sensitivity: 5mV/Div - 20V/Div
• Sensitivity error: < 5%
• Resolution: 12-bit
• Input Impedance: 1M ohm
• Maximum input voltage: 50Vpk
• Coupling: DC, AC, GND
• Max real-time sampling rate: 1Msps
• Timebase: 10us/Div - 500s/Div
• Record length: 1024
• Trigger modes: Auto, Normal, Single
• Trigger types: Rising/falling edge
• Trigger position: 1/2 of buffer size fixed
• 2.4-inch color TFT LCD with 320 x 240 resolution
• Power supply: 9V DC (please make sure the power supply is 9V, lower or higher than 9V will cause problems.)
• Supply current: 120mA @ 9V
• Dimension: 115mm x 75mm x 22mm
• Weight: 100 gram (not including cables and power supply)
