1HZ-500KHz DDS Function Signal Generator

1Hz - 500Khz sinus, blokgolf, zaagtand functie generator.

Specifications:

• The main output waveform : sine wave and square-wave, e wave, sawtooth wave
• Maximum output amplitude:± 10Vpp (no-load)
• Output impedance :50Ω±10%
• Dc bias: ± 10V (no-load)
• Display: LCD1602
• Output frequency range:
  • Sine wave: 1Hz-500KHz
  • Square-wave: 1 Hz - 20kHz (the valid range)
  • e wave :1 Hz - 20KHz (the valid range)
  • Sawtooth wave :1 Hz ~ 20kHz (the valid range)
• Resolution :1 Hz
• Power supply: DC 3.5-10V
