Mastech MS8910 SMD Tester, Multimeter (zonder doos)

Mastech MS8910 multifunctionele SMD tester. Test weerstand, capaciteit, continuïteit en diode.

Features:

• Auto Scanning to Test Resistance, Capacitance, Continuity and Diode
• Auto Power Off
• Low Battery Indicator
• The Tester is a handheld and battery operated very convenient small Tool that is specially used to measuring SMD (Surface Mounting Device)
• 3000 counts LCD display
• Full automatic measurement
• Auto scanning the Resistance/Capacitance/Diode
• Function selection by one FUNC Push Button
• Data Hold function
• Continuity Checking function
• Over Load Indication ( OL)
• Low Battery Indication
• Power Supply: 3V Lithium Battery CR2032
• Auto Power OFF. If the Tester is idle for more than 10 minutes, the tester will automatically turn off the power .
• Operating temperature & Humidity: 0 ~ 40C(32 ~104F) & < 80% RH
• Storage temperature & Humidity: -10 ~ 50C (14 ~ 122 F) & <70%RH
• Safety Class: IEC61010-1, 50V CAT III
• EMC: According to CE regulation 89/336.
• Dimension (L x W x H) & Weight: 170 x 31 x 17mm, Approx. 48.6 g

Resistance

• 300 0.1 ±(1.0% of rdg + 2 digits)
• 3K 1
• 30K 10
• 300K 100
• 3M 1K
• 30M 10K ±(1.2% of rdg + 3 digits)

Capacitance

• 3n 1p ±(2.5% of rdg + 3 digits)
• 30n 10p
• 300n 100p
• 3µ 1n
• 30µ 10n
• 300µ 100n ±(3.0% of rdg + 3 digits)
• 3m 1µ
• 30m 10µ

- Continuity The buzzer will sound if the resistance is less than 30 ohms
- Diode Check Testing current: 2mA Open Circuit voltage: 2.8 V

Accessories:

• Two free replace test pins
• English manual
• Plastic carrying case
